🧩 Product Overview: The 100W 5A USB-C Fast Charge Trigger Board Module is a highly versatile and efficient decoy board designed to support various fast charging protocols. This module is compliant with Power Delivery (PD) specifications including both PD 2.0 and PD 3.0, as well as Quick Charge (QC), FCP, and AFC, allowing for customizable voltage outputs. With its free mode switch, users can easily configure settings to support only the PD protocol if desired.
🔧 Key Features:
- Versatile Voltage Decoy Output: The module can provide decoy outputs of 5V, 9V, 12V, and 20V, depending on the capabilities of your power supply.
- Safety First: Equipped with a key lock function to prevent misoperation, the device safeguards connected load equipment by avoiding incorrect voltage settings.
- Intuitive LED Indicators: The output voltage settings are easily monitored through LED indicators, ensuring users can effortlessly keep track of the selected voltage.
- Energy Efficient: With ultra-low power consumption while maintaining high current outputs, this module supports up to 100W, making it suitable for robust charging needs.
- Automatic Voltage Maintenance: The module intelligently polls to achieve the highest voltage output and maintains it, while also providing various test functions including an infinite loop voltage cycle.
- Durable Design: The Type-C connector is designed for durability, ensuring long-term performance without wear.
🛡️ Operational Features:
- Adjustable Test Jump Time: The test jump time can be modified for precision testing, catering to various applications including aging tests, where the module can withstand voltages over 30V.
- Five Independent Key Interfaces: Users can connect up to five independent key interfaces for quick voltage switching, allowing for flexibility in operation.
- Customizable Short-Circuit Functionality: Features like PD ONLY and DM/DP short circuit options provide specialized configurations for enhanced usability, though short-circuiting is generally not recommended.
- Advanced Voltage Switching Features: Users can execute complex functions like automatic polling for the highest supported voltage or enabling an infinite loop through short circuits of keys F1 and F2.
🧩 User-Friendly Configuration: When F1 and F2 keys are shorted, the module supports a polling time setting functionality. By following a simple sequence, users can customize their switching time, enhancing the adaptability of the device to meet specific testing requirements.
🔋 Conclusion: The 100W 5A USB-C Fast Charge Trigger Board Module stands out as an essential tool for anyone involved in fast charging technology, offering a powerful combination of versatility, efficiency, and control. Whether for personal use or professional testing, this module delivers performance that meets a variety of charging needs seamlessly.
