50KG Load Cell - Versatile Half-Bridge Strain Gauge Weight Sensor
ð ïļ Introducing the 50KG Load Cell, a highly efficient half-bridge strain gauge human scale weight sensor designed for precision weight measurements. This advanced weighing sensor kit is compatible with Arduino, allowing for seamless integration into various projects and applications.
ð§ Key Features:
- Measurement Range: Capable of accurately measuring weights up to 50kg, making it ideal for personal scales, industrial weighing applications, and robotics.
- Zero Output: Achieves a consistent Âą0.3mV/V, ensuring reliable baseline measurements.
- Output Sensitivity: Offers exceptional sensitivity with an output of 1.0Âą0.15mV/V.
- Linearity: Delivers remarkable linearity with 0.2% F.S. (Full Scale), ensuring accurate readings across the measurement range.
- Hysteresis and Repeatability: Features hysteresis and repeatability of 0.2% F.S. and 0.1% F.S. respectively, making it a reliable choice for precise measurements.
- Temperature Performance: Operates effectively within a temperature range of -10â to +40â, with minimal drift in zero output (0.3% F.S. per 10â). Temperature sensitivity drift is similarly low.
- Maximum Overload: Robust design allows for a maximum overload capacity of 150% F.S., enhancing durability and reliability.
- Cable Length: Comes with a 45cm cable for easy connectivity and installation.
ðŠķ This sensor employs a set of half-bridge strain gauges and can be configured in multiple ways for different applications:
- Single Sensor Configuration: Utilize with an external resistor to create a full bridge measurement, achieving a range of 50kg. This option requires a high-quality external resistor for optimal performance.
- Dual Sensor Configuration: By implementing two sensors in a full bridge setup, the combined measurement capacity increases to 100kg.
- Quad Sensor Configuration: Connecting four sensors allows for an impressive measurement range of 200kg, suitable for heavier applications.
ð With its high accuracy, versatility, and performance optimization, the 50KG Load Cell is an excellent choice for hobbyists, educators, and professionals seeking a reliable weight sensor for their projects.
