🏎️ Product Name: L925BP Black Fiber Optic Mechanical Splice Fiber Fixed Length Stripper Coating Layer Fixed Length Guiding Fast Connector FTTH
🧠 Overview: The L925BP is a sophisticated mechanical splice solution specifically designed for fiber-to-the-home (FTTH) applications. This advanced connector enables seamless integration between home butterfly cables and various Flexer pigtails, ensuring a cost-effective and efficient connection. With its mature V-slot docking technology, the L925BP is particularly suited for multimode fiber connections, making it a versatile choice for modern networking needs.
🔧 Key Features:
- Time-Efficient Operation: Designed for rapid installation, the L925BP allows operators to complete setups in under a minute with its user-friendly, free fixture design.
- High Tensile Strength: Capable of withstanding tension exceeding 5KG, making it an excellent choice for reliable connections in residential settings.
- Versatile Applications: The L925BP is highly adaptable, ideal for network upgrades in existing residential areas as well as for the reconstruction of optical fiber networks.
- Cost Reduction: By minimizing the need for panel boxes and supporting flanges, the L925BP significantly lowers overall fiber access costs while maintaining ease of use.
- Compatible Designs: This connector accommodates a variety of fiber types, allowing for flexible combinations with SC, FC, LC, ST, and others.
⚡ Technical Specifications:
- Applicable Cable Type: 3.1 x 2.0mm dish optical cable
- Fiber Diameter: 125µm (657A/657B)
- Tight Cladding Diameter: 250µm/900µm
- Operational Modes: Supports both single mode and multimode fibers
- Insertion Loss: Less than 0.15dB at 1310nm and 1550nm
- Return Loss: Greater than -45dB
- Success Rate: Over 98% in continued operations
- Durability: Can be assembled and disassembled more than 10 times without performance degradation
- Tensile Strength: Exceeds 50N
- Operating Temperature Range: -40°C to +85°C
- Impact Resistance: Passed drop tests from 4 meters onto a cement floor (3 times), with insertion loss ≤ 0.2dB
💥 The L925BP Black Fiber Optic Mechanical Splice is engineered for high-performance connectivity, ensuring long-lasting durability and reliability in a variety of environments. Ideal for technicians and network installers, it delivers exceptional efficiency and versatility in fiber optic deployments.
