Product Overview:
⚡ Introducing the 1 Port CAT8/CAT7 RJ45 Wall Panel, an advanced network installation solution designed for seamless connectivity in both residential and commercial environments. This top-quality Ethernet wall socket is engineered to support high-speed networking needs, making it an ideal choice for gamers, streamers, and anyone requiring reliable internet access.
Specifications:
- Color: Classic White
- Type: Options for CAT7 or CAT8 RJ45 connections for enhanced performance
- Version: Extrusion wire for optimized signal transmission
- Case Material: Premium Zinc Alloy for durability and protection
- DC Resistance: ≤300mΩ for efficient conductivity
- Insulation Resistance: ≥500mΩ ensuring safety and reliability
- Contact Resistance: ≤20mΩ minimizing signal loss
- Operating Temperature: Suitable for a range of -10℃ to 60℃ for versatile installation
- Compressive Strength: Rated at 1000V (AC750V) for robust performance
- Core Composition: Features an 8-core copper needle made from phosphor bronze with gold plating for superior conductivity
- IDC Terminal: Compatible with 23-26AWG conductors for flexible wiring options
- Dimensions: Compact size of 86mm x 86mm for easy installation and integration into wall systems
🧩 Please Note:
- Color variations may occur due to differences in lighting and screen display.
- Allow for minor measurement discrepancies of 1-3cm as each product is manually checked.
📦 Package Includes:
1 x Network Panel Socket
