High - Efficiency Adjustable Voltage Regulator Module - Low Ripple, 5A Output - 12V

📦 Product Overview:
The DC-DC Buck-Boost Module is a versatile power supply solution designed to convert input voltages from 3.6V to 32V into stable output voltages of 5V, 9V, or 12V, with a maximum current output of 5A. This compact module is ideal for a wide array of electronic projects, offering high efficiency and reliable performance in various environments.

🔧 Key Features:

• Wide Input Voltage Range: The module supports a broad input voltage range from 3.6V to 32V, allowing it to be used in diverse power supply environments.
• Stable Output Options: Choose between output voltages of 5V, 9V, or 12V, with a robust maximum output current capacity of 5A to effectively power different types of devices.
• Compact and Lightweight Design: Its small size and light weight make it easy to integrate into various electronic devices or DIY projects without adding significant bulk.
• Robust Protection Mechanisms: The module includes built-in protections against short circuits and over-temperature conditions, ensuring the safety of both the module and any connected devices.
• Durable Performance: Designed to operate in harsh conditions, this module offers long-term stability and reliability, making it suitable for demanding applications.

🛡️ Technical Specifications:

• Input Voltage: 3.6V-32V DC
• Output Voltage Options: 5V, 9V, 12V
• Maximum Working Current: 5A
• Operating Temperature Range: -40°C to +125°C

📦 Product Description:
Utilizing a premium original chip and high-quality Samsung capacitors, this module achieves an impressive power output in a compact form factor. The innovative design incorporates an external MOSFET to ensure efficient voltage boosting while maintaining a low profile. Initially operating in DCM mode, the module consumes less than 1mA of power during startup, before entering CCM mode under load, where quiescent current rises to about 20mA. This makes it suitable for applications with low static power requirements.

💍 Wiring Instructions:
- IN+: Connect to DC input positive (3.6V-32V).
- IN-: Connect to DC input negative, which should also link to the output negative terminal.
- OUT+: Connect to DC output positive.
- OUT-: Connect to input negative terminal for proper functionality.

🧩 Important Considerations:
1. The combined input and output must not exceed 5A; it is advisable to maintain a safety margin to prevent excessive heat generation.
2. Use appropriately rated wiring to handle the corresponding current without overheating.
3. Implement protective measures for inductive loads to avoid damaging reverse electromotive forces.
4. Expect increased heat output as module power approaches maximum capacity; ensure adequate heat dissipation.
5. For continuous use, it is recommended to keep the current below 3A without external cooling; exceeding this may require additional heat management.
6. It is advisable to keep input voltage under 30V, as unstable supply voltage could trigger the internal over-voltage protection when peaks exceed 32V.

📦 Package Contents:
- 1 x Boost Buck Module
