Product Overview:
📶 Introducing the 5pcs NRF24L01+PA+LNA Wireless Transceiver RF Module, an advanced 2.4GHz wireless communication solution designed for optimal performance and enhanced range. This upgraded version of the NRF24L01+ boasts a power amplifier (PA) and low-noise amplifier (LNA), allowing for seamless wireless data transmission over impressive distances of over 800 meters in unobstructed scenarios.
🔧 Key Features:
- Impressive Range: Achieve reliable communication up to 800+ meters, making it ideal for various applications, from remote sensing to IoT projects.
- Dual-Functionality: Compatible with multiple microcontrollers including MCU, ARM, PIC, AVR, and STM32, offering versatile integration options for your projects.
- Configurability: Easily configure the module via a 4-pin Serial Peripheral Interface (SPI). Choose from 125 selectable frequency channels and set output power and data rates of 250kbps, 1Mbps, or 2Mbps.
- Voltage Flexibility: The on-chip voltage regulator supports input voltages from 1.9V to 3.6V, while also featuring 5V tolerant inputs to simplify connections with compatible boards like Arduino IDE.
- Efficient Modulation: Utilizing Gaussian Frequency-Shift Keying (GFSK) modulation and fast Automatic Gain Control (AGC), this module ensures a stable and efficient transmission process.
- Energy Management: Equipped with an Interrupt Request (IRQ) pin, this feature allows the microcontroller to enter a low-power sleep mode, waking up only upon receiving transmissions, thus maximizing battery life for portable applications.
⚡ Specifications:
- Frequency: 2.4GHz ~ 2.5GHz
- Operating Voltage: 3V ~ 3.6V
- Maximum Current Draw: 115mA
- Multi-frequency Support: 125 channels available
⚡ Included in the Package:
- Modules: Choose between 1, 3, or 5 wireless modules
- Antenas: Options to include 1, 3, or 5 antennas
- Socket: Select 1, 3, or 5 sockets
📶 Whether you're a hobbyist or a professional engineer, the NRF24L01+PA+LNA module is designed to elevate your wireless communication projects to new heights. It's the perfect blend of cost-effectiveness and high-performance technology!
