Introducing the 32-Channel LED Motion Sensor Stair Light Strip Controller
🤖 This innovative controller is designed to provide enhanced lighting for stairways through smart motion detection. Ideal for both home and commercial use, it operates on a low voltage of DC 12V or DC 24V with a maximum power output of 500W, making it a reliable choice for your lighting needs.
🔧 Key Features:
- Channel Control: With 32 adjustable channels, you have the flexibility to customize your stair lighting setup by programming each step individually.
- PIR Sensors: Equipped with two passive infrared (PIR) sensors that detect motion effectively, ensuring that your lights turn on as soon as they sense a person's presence.
🧩 Functionality:
- Speed Adjustment: Easily customize the light strip's activation speed with four settings: 15 seconds, 30 seconds, 45 seconds, and 60 seconds. This allows for a tailored experience to suit your specific environment.
- Step Setting Mode: Activate the step setting mode by pressing and holding the key for 5-6 seconds. This feature allows you to designate specific lighting for each step, enhancing safety and visibility.
- Follow the simple procedure to set the steps:
- Long press the switch to set the first step.
- Short press to set subsequent steps, adjusting the lighting for each step accordingly.
- Once your settings are complete, save them by long pressing the switch again for 5-6 seconds.
🧩 Installation Notes:
- Position the A/B sensors at key locations at the entrance and exit of the stairs, ensuring they face towards the user for optimal functionality.
- This product requires connection to a transformer as it operates at low voltage. Do not connect directly to 220V to prevent damage to the controller.
- Please note, the controller is not waterproof, so installation in a dry environment is recommended.
💧 Wiring Instructions:
💍 To set up the controller properly, ensure correct wiring: the red wire (V+) must connect to the positive terminal of the switching power supply, while the blue (or black) wire (V-) connects to the negative terminal. Reversing these connections can result in damage to the device.
📦 Package Contents:
📎 1 PC LED Controller (Note: LED strip and power supply are not included)
